Octopus® Series containerized energy storage solution
The Octopus Series battery system is available in a containerized solution, including the Octopus Battery Management Platform for smooth operation. The containerized Octopus Series is a maritime energy storage solution available in different sizes and it can be used for many maritime applications.
The customized containerized solutions are suitable for Maritime purposes, either mobile or stationary. Together with our partners we customize our energy storage solutions in an ISO 10, 20ft or high cube container or larger if required. The DC or AC Energy Containers can store 126 kWh up to 2 MWh of energy.
This containerized energy storage is a flexible solution for all refits, retrofits, upgrades or conversions to upgrade or renew your existing fleet.
This solution can be used to supply energy for electrical or hybrid propulsion. It can function for different application needs.
There is no space needed on board for a dedicated battery room and it is an easy way to expand your capactiy with a zero-emission energy supply.
The containerized energy storage is an easy solution if you’re looking for a sustainable energy supply for a refit, retrofit, upgrade of your vessel or conversion
The containerized battery room can be used as a range extender or to enhance the capabilities of your vessel.
With the containerized solution it becomes more easy to expand the capacity of the energy storage if needed.
Often space onboard is limited, if you can’t make space for a dedicated battery room a fully certified containerized solution might be the answer for you.
The energy storage container can be used as a replacement for generator-sets and deck equipment
If preferred it is possible to make the container swappable, meaning that you can remove the container used batteries that need to reload for a container with a fully charged battery system
|Containerized Octopus Series||High Energy||High Power||Lite XL|
|Container||10-20ft (HC)||10-20ft (HC)||10-20ft (HC)|
|Voltage||500-100 VDC||500-100 VDC||500-100 VDC|
|Capacity||100-2000 kWh||50-1400 kWh||150-2800 kWh|
|(Dis-)charging||0.5 C cont - 1 C max||2.0 C cont - 3.0 C max||0.3 C cont - 0.5 C max|
|Vibration and shock||UNT38.3, DNV 2.4, IEC 60068-2-6|
